Manual Plastic Amiad Series
Filtration- Flow
- Up to 220 gpm (50 m³/h)
- Pressure
- Filtration 50–3,500 micron
- Sizes
- 3/4"–3"
- Best for
- The small manual filter most greenhouse and nursery heads actually need — plastic body, screen or disc element, and the widest filtration range in the manual line
Catalog ↗Manual Plastic Arkal Series
Filtration- Flow
- Up to 705 gpm (160 m³/h)
- Pressure
- Filtration 20–800 micron
- Sizes
- 3/4"–6"
- Best for
- Disc filtration down to 20 micron — finer than a screen of the same size will hold, and the grooved discs give depth filtration that copes with organic matter rather than blinding off
Catalog ↗Manual Plastic Tagline Series
Filtration- Flow
- Up to 220 gpm (50 m³/h)
- Pressure
- Filtration 80–500 micron
- Sizes
- 3/4"–3"
- Best for
- Compact manual filter in screen or disc for small heads and sub-mains
Catalog ↗Manual Steel Series
Filtration- Flow
- Up to 1,320 gpm (300 m³/h)
- Pressure
- Filtration 50–3,500 micron
- Sizes
- 2"–8"
- Best for
- Steel-bodied manual screen filter for mainline duty where a plastic body will not take the pressure or the handling
Catalog ↗Brushaway Series
Filtration- Flow
- Up to 1,320 gpm (300 m³/h)
- Pressure
- Filtration 200–3,500 micron
- Sizes
- 2"–8"
- Best for
- Turn the handle and internal brushes sweep the screen — cleans without opening the housing or stopping irrigation, which is the practical difference between a filter that gets serviced and one that does not
Catalog ↗Scanaway Series
Filtration- Flow
- Up to 1,320 gpm (300 m³/h)
- Pressure
- Filtration 50–500 micron
- Sizes
- 2"–8"
- Best for
- Same manual-cleaning convenience as the Brushaway but with a suction scanner, taking it down to 50 micron for drip systems
Catalog ↗TAF Series
Filtration- Flow
- Up to 220 gpm (50 m³/h)
- Pressure
- Filtration 10–500 micron
- Sizes
- 2"–3"
- Best for
- The smallest fully automatic Amiad filter, and the one that fits a greenhouse head. Self-flushes without interrupting flow, down to 10 micron
Catalog ↗Mini Sigma Series
Filtration- Flow
- Up to 352 gpm (80 m³/h)
- Pressure
- Filtration 50–500 micron
- Sizes
- 2"–4"
- Best for
- Compact automatic screen filter for small to mid-size blocks
Catalog ↗Sigma Pro Series
Filtration- Flow
- Up to 1,233 gpm (280 m³/h)
- Pressure
- Filtration 50–500 micron
- Sizes
- 4"–8"
- Best for
- Mid-size automatic screen filtration for a whole nursery mainline
Catalog ↗M100 Series
Filtration- Flow
- Up to 1,760 gpm (400 m³/h)
- Pressure
- Filtration 80–500 micron
- Sizes
- 2"–4" (up to 440 gpm) and 4"–10" (up to 1,760 gpm)
- Best for
- Patented automatic screen filter across two size bands, so one family covers a small head or a full mainline
Catalog ↗SAF Series
Filtration- Flow
- Up to 1,760 gpm (400 m³/h)
- Pressure
- Filtration 10–800 micron
- Sizes
- 2"–10"
- Best for
- Suction scanning combines a focused flush with a scanner sweeping a multi-layered stainless screen, so it self-cleans efficiently on dirty water. Widest filtration span in the automatic range
Catalog ↗MG Series
Filtration- Flow
- Up to 3,520 gpm (800 m³/h)
- Pressure
- Filtration 80–500 micron
- Sizes
- 10"–14"
- Best for
- Large-diameter automatic screen filtration for a pump station feeding several blocks
Catalog ↗ABF Series
Filtration- Flow
- Up to 32,000 gpm (7,200 m³/h)
- Pressure
- Filtration 200–3,500 micron
- Sizes
- 3"–36"
- Best for
- Coarse automatic pre-filtration ahead of the fine filters, for surface water carrying weed and debris
Catalog ↗Spin Klin Compact Angle 2"
Filtration- Flow
- Up to 66 gpm (15 m³/h)
- Pressure
- Filtration 20–400 micron
- Sizes
- 2"
- Best for
- The smallest automatic Spin Klin — one 2" unit for a single greenhouse or a propagation house. Polymeric grooved discs give depth filtration with high dirt-holding capacity and hold organic matter far better than a screen
Catalog ↗Spin Klin Batteries 2" / 3"
Filtration- Pressure
- Filtration 20–400 micron
- Sizes
- 2" battery 3"–6" (up to 530 gpm) · 3" battery 6" (up to 880 gpm)
- Best for
- Spin Klin units ganged into a battery so capacity scales with the block — one unit backflushes while the rest keep filtering, so supply never stops
Catalog ↗Spin Klin Apollo / Galaxy
Filtration- Pressure
- Filtration 20–400 micron
- Sizes
- Apollo 4"–8" (1,409 gpm) · Apollo Twin 10"–12" (3,520 gpm) · Galaxy 8"–16" (13,200 gpm)
- Best for
- The large end of the Spin Klin range for pump stations and multi-block sites
Catalog ↗Media Series
Filtration- Flow
- Up to 330 gpm (75 m³/h) per unit
- Sizes
- 20"–48"
- Best for
- Media filtration for surface water with heavy algae or organic load, where screens and discs blind off too fast. Sand, glass, active carbon, anthracite or basalt media, with tank materials meeting international drinking water standards
Catalog ↗AGF Series
Filtration- Flow
- Up to 308 gpm (70 m³/h) per unit
- Sizes
- 48"
- Best for
- Large-vessel media filtration
Catalog ↗Sand Separator Series
Filtration- Flow
- Up to 110 gpm (25 m³/h)
- Sizes
- 2"
- Best for
- Spins sand out before it reaches the filter — for well water carrying grit, it saves the filter from doing work it was never meant to do
Catalog ↗ADI-P Controller
Filtration- Sizes
- One or two solenoid configurations
- Best for
- Runs the automated flush cycle on Amiad automatic filters, with monitoring — the piece that makes a self-cleaning filter actually self-cleaning
Catalog ↗
