Fogg-It Nozzle - Super Super Fine
Mister & fogger- Flow
- 1/4 GPM @ 40 {PSI
- Sizes
- Item 610SSF
- Best for
- The Fogg-It Nozzle is designed for misting delicate seedlings or for raising humidity around wilting plants. This nozzle has three mist jets which create a conical spray pattern. Available in 4 different discharge rates. Made in the U.S.A. from solid brass. 3/4 hose threads. Available in 4 different flow rate sizes.
Catalog ↗Fogg-It Nozzle - Super Fine
Mister & fogger- Flow
- 1/2 GPM @ 40 PSI · 1 GPM @ 40 PSI · 2 GPM @ 40 PSI · 4 GPM @ 40 PSI
- Sizes
- Item 610SF, 610F, 610L, 610H
Catalog ↗JetFog Barbed Nozzle
Mister & fogger- Sizes
- Item JFSB · Sizes -
- Best for
- JetFog low-pressure fog nozzle with a barbed inlet, for pushing straight onto tube. Item JFSB — order JFST instead if the line is threaded.
Catalog ↗JetFog Threaded Nozzle
Mister & fogger- Sizes
- Item JFST · Sizes -
- Best for
- JetFog low-pressure fog nozzle with a threaded inlet, for screwing into a fitting or riser. Item JFST — order JFSB instead for barbed tube.
Catalog ↗JetFog 2 way Barbed
Mister & fogger- Sizes
- Item JFB2 · Sizes -
- Best for
- Two outlet nozzle with barbed inlet. Flow rate is 11.6 lph (3 gph).
Catalog ↗JetFog 4 way Barbed
Mister & fogger- Sizes
- Item JFSB4 · Sizes -
- Best for
- Four outlet nozzle with barbed inlet. Flow rate is 23.2 lph (6 gph).
Catalog ↗JetFog 5 way Barbed
Mister & fogger- Sizes
- Item JFSB5 · Sizes -
- Best for
- Five outlet nozzle with barbed inlet. Flow rate is 29 lph (7.5 gph).
Catalog ↗JetFog 4 way Threaded
Mister & fogger- Sizes
- Item JFST4 · Sizes -
- Best for
- Four outlet nozzle with threaded inlet. Flow rate is 23.2 lph (6 gph).
Catalog ↗JetFog 5 way Threaded
Mister & fogger- Sizes
- Item JFST5 · Sizes -
- Best for
- Five outlet nozzle with threaded inlet. Flow rate is 29 lph (7.5 gph).
Catalog ↗2 way cross for JetFog
Mister & fogger- Sizes
- Item JF-2CROSS · Sizes -
- Best for
- Two way cross for JetFog Nozzle. Press fit connection.
Catalog ↗4 way cross for JetFog
Mister & fogger- Sizes
- Item JF-4CROSS · Sizes -
- Best for
- Four way cross for JetFog Nozzle. Press fit connection.
Catalog ↗Misty Mist Nozzle
Mister & fogger- Sizes
- Item MM-RW, MM-KW · Sizes 1.25 mm, 1.50 mm · Colors Red / White, Black / White
Catalog ↗High Pressure Misty Mist Nozzle
Mister & fogger- Sizes
- Item HP-GW · Sizes 0.75 mm · Colors Grey / White
- Best for
- The High Pressure Misty Mist delivers an ultra fine spray, ideal for mist cooling and raising humidity levels. These nozzles create a 10 foot diameter spray pattern. High Pressure Misty Mist Nozzles should only be installed on the topside of the pipeline. Bottom side installations are not recommended due to the high pressures involved. Space nozzles 10 feet apart with the pipeline suspended as high as possible in the middle of each bay, without interfering with the spray pattern of the nozzle. There is no need to worry about overlapping spray patterns since the goal is to evaporate water into the air versus allowing the water to drop to the soil. Please note that high pressure pumps and filtration equipment are required for these nozzles to work properly. High Pressure Misty Mist Nozzles can not be installed using Assembly Inserts. Threads must be tapped directly into the water pipeline, use the drill & tap installation method explained at the end of this section. Before you begin an installation, we recommend that you install one pipeline based on the guidelines presented. After the first pipeline is installed, tested and adjusted, remaining lines can be set-up following the same specifications as the first. Use High Pressure 360° Misty Mist Nozzles in combination with Dramm Run-Out Valves to control water drip.
